Core Configuration
●Sensing & Data Acquisition: High-precision sensor
●Control System: Panasonic full-digital AC servo controller
●Measurement & Control Software: Full-digital closed-loop control system, running at constant speed with stable operation
●Test Platform Lifting Device: Computer digital control / Manual jog control
●Safety Protection for Test Platform: Automatic software diagnosis, electronic limit protection
●Test Return Function: Manual return to initial position at maximum speed; automatic return upon test completion
●Overload Protection: Max load value configurable with automatic overload protection
●Fixture Assembly: Pneumatic lower fixtures, individually controllable
Technical Specifications
| Number of Stations | 5 sets |
| Max Test Force per Station | 1KG–20KG optional (customizable for larger ranges) |
| Accuracy Grade | Class 0.5 |
| Test Force Measuring Range | 0.01–100% of full load |
| Test Force Indication Error | 0.5% |
| Test Force Resolution | 1/500000 |
| Test Speed | 0.5–500mm/min |
| Speed Accuracy | Within ±0.5% of reading |
| Displacement Accuracy | Within ±0.5% of reading |
| Max Specimen Width | 90mm max |
| Test Space (Column Length) | 850mm |
| Overall Dimension | 850×600×1300mm |
| Power Supply | 220V/50Hz±10%, 0.75KW |
