Product Features
●The structure is made of the paint-coated aluminium blanking plate. The interior is used the high-accuracy,low-resistance and zero clearance of two ball screw and oriented pole which improve loading efficient and structure rigidity.
● Use Panasonic servo motor which ensure high efficiency,steady transmission and low noise. The accuracy of speed can be controlled in 2%.
●That Using the business computer as the main control machine plus the special testing software of our company can conduct all of testing parameter, work state, collecting data&analysis, result display and printing \output.
●Have steady performance, high accuracy, powerful software function and easy operation.
● Use double insulated glass, user-friendly observing test; Adopt stainless steel frame and bladder, not only beauty but corrosion resistance.
Compliance with Standards
●GB10586-89
●GB/T7750-1987
●GB2423.1-89
●GB2423.2-89
●GJB150.3-86
Technical Specifications
| Load Capacity | 10kg |
| Capacity Selection Principle | Generally 3~10 times the maximum breaking force of the specimen |
| Unit Selection | g, kg, N, kN, LB (International standard, metric and imperial units available, freely switchable) |
| Force Display | Full computer control, operated under Windows system |
| Load Resolution | 1/250,000 |
| Load Accuracy | ≤0.5% |
| Test Speed | 1~500mm/min stepless speed regulation, adjustable arbitrarily via computer |
| Test Stroke | 400mm for high-low temperature chamber version; 1200mm for standard version |
| Test Width | 40cm inside high-low temperature chamber; 80cm for standard version |
| Effective Test Space (Inside Temperature Chamber) | (D×W×H) 40×40×70cm |
| Drive System | Japan Panasonic AC servo motor and driver |
| Transmission Mode | High precision ball screw |
| Machine Overall Dimension | Main unit (W×D×H): 1200×520×1950mm (test bench height: 50cm) |
| Machine Weight | 130KG |
| Power Supply | 1∮, AC220V / 50Hz |
| Rated Power | 0.4KW. Different power Panasonic servo motors equipped according to different load requirements |
| Fixtures | One set each of tensile fixture, loop initial tack fixture and peel test fixture as per customer product requirements |
Technical Specifications(Temperature control system)
| Temperature Range | －40℃～150℃ |
| Temperature Fluctuation | ±0.5℃ |
| Temperature Deviation | ≤±2℃ |
| Heating Time | Approx. 55 mins from -40℃ to 150℃ (no load) |
| Cooling Time | Approx. 60 mins from +20℃ to -40℃ (no load) |
| Humidity Range | 20～98% R.H |
| Humidity Fluctuation | 2.5% R.H. |
| Humidity Deviation | ≤±3% R.H. |
