KJ-6040 Surface Friction Coefficient Tester

The KJ-6040 Surface Friction Coefficient Tester is a high-precision testing instrument specially developed for plastic films, sheets and similar materials. Its core function is to accurately measure the static and dynamic friction coefficients of the materials. With its professional detection performance and convenient operation experience, it has become a key support for production quality control and process optimization in the packaging and plastic industries. It fully complies with both international and domestic standards, providing authoritative data support for product quality improvement.

Inquire Now Next Product

Application

Core purpose: Precisely control material properties and optimize production processes

The equipment focuses on the friction performance testing of plastic films, sheets and similar materials. It is equipped with professional control software, which can visually present the smoothness and opening properties of the materials. Through dynamic curves, it can display the distribution of the lubricant, making the detection data more valuable. By accurately measuring the smoothness of the materials, it can directly guide the production process - effectively controlling and adjusting the opening properties of packaging bags, optimizing the packaging machine's packaging speed, avoiding production problems such as film sticking and slipping, ensuring that the products meet the actual usage requirements, improving production efficiency and product qualification rate, and helping enterprises achieve refined quality control.

KJ-6040 Surface Friction Coefficient Tester

Executive Standard

GB/T10006: Determination of Friction Coefficients for Plastic Films and Sheets

ASTM D1894-24: Standard Test Method for Static and Kinetic Coefficients of Friction of Plastic Film and Sheeting

ISO8295: Plastics - Film and Sheeting - Determination of the Coefficients of Friction

Standard Configuration

Mainframe: Core detection equipment, integrating all functional modules such as driving, sensing, and display

Miniature printer: Capable of instantly printing detection data, facilitating archiving, comparison analysis

200g slider: Standard configuration, meeting mainstream testing requirements, ensuring the standardization of the detection process

Technical Parameter

Sample thickness	≤0.2mm
Slider size	63×63mm(Meets standard requirements, ensuring uniform pressure distribution）
Slider weight	200±2g
Test table size	170×225mm，can smoothly accommodate the sample, ensuring test stability
Measurement accuracy	±2%，equipped with high-precision sensor, resulting in small data error
Test speed	50~150±10mm/min adjustable
Slider stroke	Maximum 100mm (Adjustable, meeting the testing requirements for different samples)
Force range	0-5N, covering the detection needs of most plastic films and thin sheets
Overall dimensions	Approximately 500 × 335 × 220 mm
Power supply	AC220V±22V, 50Hz

Do We Need To Offer You Any Assistance?

Looking ahead, Guangdong Kejian Instrument Co., Ltd. will continue to uphold the core philosophy

+86 139 2947 7992

+86 139 2551 9875
sale056@kejian-tech.com

sale069@kejian-tech.com

Free consultation. No commitment required.

FAQ

Q:
Are you a factory or a trading company?

A:

We are a professional testing instrument manufacturer with over 20 years of experience, a national high-tech enterprise and a “Specialized, Sophisticated, Unique and New” certified enterprise.
Q:
What materials can your testing machines test?

A:

Our testing machines are suitable for peel,shear, tensile, release force and adhesive strength tests on adhesive tapes, self-adhesive labels, protective films, release papers, release films, foams, films, papers, rubbers and other materials.
Q:
Which international test standards do your equipment comply with?

A:

Our equipment supports major international standards including ASTM D3330, FINAT, GB/T 2792, PSTC, etc.
Q:
Is the software in Chinese or English?

A:

The software supports both Chinese and English interfaces, switchable freely for global users.
Q:
Is the operation difficult? Do you provide training?

A:

The interface is user-friendly. We provide free online training, video tutorials and English manuals.

Q:
How long is the warranty period?

A:

12-month warranty for the whole machine, with lifetime technical support.
Q:
How to solve equipment failures?

A:

We provide fast response via remote assistance, telephone and email. On-site service can be arranged if required.
Q:
Can accessories and fixtures be purchased separately

A:

Yes, we supply original accessories, fixtures and wearing parts for a long term.
