Product Features
●The structure is made of the paint-coated aluminium blanking plate. The interior is used the high-accuracy,low-resistance and zero clearance of two ball screw and oriented pole which improve loading efficient and structure rigidity.
●Use Panasonic servo motor which ensure high efficiency,steady transmission and low noise. The accuracy of speed can be control in 0.5%.
●That using the business computer as the main control machine plus the special testing software of our company can conduct all of testing parameter, work state, collecting data&analysis, result display and printing output.
Compliance with Standards
ASTM D3330
FINAT
GB/T2792
PSTC
Accessories
●Suitable Grips that meet customer sample need.
●Software for test control,data acquisition and report.
●English operation teach video.
●Table computer is select.
●Extend meter as customer request.
Technical Specifications
| Model | KJ-1066A |
| Range of speed | 0.5-1000mm/min |
| Motor | Japan Panasonic Servo Motor |
| Capacity choice | 2000 kg |
| Resolution | 1/250,000 |
| Effective testing space | 400mm MAX |
| Accuracy | ±0.5% |
| Operation method | Windows XP, Win7 operation, computer control |
| Accessories | computer, printer, system operation manual |
| Optional accessories | customized clamps by appointed, force sensors, printer, and operation manual |
| Weight | 400KG |
| Dimension | (W×D×H) 80×50×150cm |
| Power | 1PH, AC220V, 50/60Hz |
| Stroke protection | Upper and lower protection, prevent over preset |
| Force protection | system setting |
| Emergency stop device | Handling emergencies |
